Panel
Panel
Aluminum frame with great heat dissipation
Super thin panels for embedding
Recessed, Surface Mounted are available.
Different UGR value, High efficiency, CCT switch, Dimmable are available
Warranty: 2 years
| Series | Model | Power | Voltage | Effecacy lm/w | lumen | PF | CRI | Dimension | Lifetime |
| RECESSED | ID-DL-SL4040 | 32W | AC100-240V | 94 | 3000 | 0.9 | 80 | 400*400mm | 25,000Hrs |
| ID-DL-SL6060 | 40W | AC100-240V | 100 | 4000 | 0.9 | 80 | 595*595mm | 25,000Hrs | |
| ID-DL-SL1230 | 48w | AC100-240V | 100 | 4800 | 0.9 | 80 | 295*1195mm | 25,000Hrs | |
| ID-DL-SL1260 | 60w | AC100-240V | 100 | 6000 | 0.9 | 80 | 595*1195mm | 25,000Hrs | |
| SURFACE | ID-SP-SL4040 | 32W | AC100-240V | 94 | 3000 | 0.9 | 80 | 400*400mm | 25,000Hrs |
| ID-SP-SL6060 | 40W | AC100-240V | 100 | 4000 | 0.9 | 80 | 595*595mm | 25,000Hrs | |
| ID-SP-SL1230 | 48w | AC100-240V | 100 | 4800 | 0.9 | 80 | 295*1195mm | 25,000Hrs | |
| ID-SP-SL1260 | 60w | AC100-240V | 100 | 6000 | 0.9 | 80 | 595*1195mm | 25,000Hrs |
* 605*605MM,620*620MM, 120MM/150MM/170MM WIDTH IS OPTIONAL. POWER CAN BE CUSTOMIZED*.
